Dahua 8 Channel 1U 2HDDs 8PoE Lite 4K H.265 Network Video Recorder (DHI-NVR2208-8P-4KS2)
*HARGA HUBUNGI KAMI
Deskripsi
System |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Main Processor | Dual-core embedded processor | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating System | Embedded LINUX | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio and Video |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
IP Camera Input | 8 Channel | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Two-way Talk | 1 Channel Input, 1 Channel Output, RCA | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Display | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Interface | 1 HDMI, 1 VGA | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Resolution | HDMI: 3840×2160, 1920×1080, 1280×1024, 1280×720 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
VGA: 1920×1080, 1280×1024, 1280×720 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Decoding Capacity | 1ch@8MP 30fps, 4ch@1080P 30fps | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Multi-screen Display | 1/4/8/9 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
OSD | Camera title, Time, Camera lock, Motion detection, Recording | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Recording |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Compression | Smart H.265+/H.265/Smart H.264+/H.264 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Resolution | 8MP/6MP/5MP/4MP/3MP/1080P/720P/D1&etc. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Record Rate | 80Mbps | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Bit Rate | 16Kbps ~ 20Mbps Per Channel | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Record Mode | Manual, Schedule (Continuous, MD (Motion Detection), Alarm, IVS) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Record Interval | 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Detection and Alarm |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Trigger Events | Recording, PTZ, Tour, Video Push, Snapshot, and Screen Tips | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Detection | Motion Detection, MD Zones: 396 (22 × 18),
and Tampering |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm input | N/A | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Relay Output | N/A | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Playback and Backup |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Sync Playback | 1/4 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Search Mode | Time /Date, MD and Exact Search
(accurate to second) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Playback Function | Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Shuffle, Backup Selection, Digital Zoom | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Backup Mode | USB Device/Network |
Third-party Support |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Third-party Support | Onvif, RTSP | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Interface | 1 RJ-45 port (10/100/1000Mbps) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
PoE | 8 ports (IEEE802.3at/af) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network Function | HTTP/HTTPS, TCP/IP, IPv4/IPv6, RTSP, UDP, NTP, DHCP, DNS, IP Filter, DDNS, IP Search(Support Dahua IP camera, DVR, NVS and etc.), P2P | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Optical Fiber Interface | N/A | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max. User Access | 128 users | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smart Phone | iPhone, iPad, Android | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Interoperability | ONVIF 2.4, SDK, CGI | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Internal HDD | 2 SATA III ports, up to 10 TB for a single HDD. The maximum HDD capacity varies with environment temperature | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
HDD Mode | Single | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
eSATA | N/A | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Auxiliary Interface |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
USB | 2 ports (1 Rear USB2.0, 1 Front USB2.0) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
RS232 | N/A | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
RS485 | N/A | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Electrical |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Supply | Single, DC54V/2.22A | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Consumption | NVR: <5.8W (without HDD) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
PoE: Max 25.5w for single port, 80w in total | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Environmental |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Conditions | -10°C to +55°C (+14°F to +131°F), 86–106kpa | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage Conditions | 0°C to +40°C (+32°F to +104°F), 30–85% RH | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Construction |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Dimensions(W×D×H) | 1U, 375 mm × 275 mm × 53 mm (14.8″ × 10.8″ × 2.1″) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Net Weight | 1.6 kg (3.53 lb) (without HDD) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gross Weight | 3.0 kg (6.61 lb) (without HDD) |
